OEV BASE CAMP Camper
The BASE CAMP bridges the gap between our CAMP-HBE camper and our SUMMIT cabin. The BASE CAMP uses the same 1.5″ (38mm) composite panel(s) to achieve the weight that we were targeting. The result has yielded an extremely lightweight spacious, comfortable cabin.
The BASE-CAMP is a fixed cabin designed specifically for 1-ton trucks with an 8-foot bed. These cabins use our proprietary composite panel and aluminum extrusion system to keep weight extremely light, extremely tough, and you extremely warm or cool! The extrusions are designed specifically for this application, the thermal transfer has been almost eliminated keeping the interior more comfortable in inclement weather.
External Dimensions: 168” L x 78” W x 64” H closed / 88” open
Internal Dimensions: 165” L x 74.5” W x 59” H closed / 83” open powder coated aluminum extrusions
OEV gen 4 composite walls and roof = 1.5” (38.1mm) (<=R8)
1.5” (38.1mm) honeycomb polypropylene floor (>=R5)
Fire-rated & insulated soft walls (>=R4) with egress windows
Locking roof supports w/electric actuators to open and close pop up roof
DOT LED lighting
Spec’d for a factory Ford F350, 4x4, 60” cab to chassis (diesel or gas) (not included)
Cabin dry weight: ~2500 lbs.
Starting Price: $159,900
Exterior Items
Cabin fixed to chassis – fully isolated
Under cabin powder-coated aluminum locking cabinets
OEV powder-coated aluminum rub rail
OEV spare tire carrier with a manual hoist will fit up to a 40”
OEV molle rack
OEV ladder
OEV folding stairs
Base Camp graphics package
Options
Additional 200W solar panel (max of 2 permitted)
Gernie-style bunk over the dinette
King bed extension w/6” mattress to match bed
Additional multispeed roof fan
OEV front cabin off-road light bar (does not include lights)
3-piece awning adapter kit for alu cab shadow 270 awning
2-piece awning adapter kit for batwing/foxwing/kinsmen
Air conditioning (split system) works in conjunction with chassis compressor (truck must be running)
Air conditioning (roof mount) – dc powered (dometic coolair rtx 1000)
Air conditioning (roof mount) – dc powered (dometic coolair rtx 2000)
Cabin to cab pass through – sliding glass window on front cabin wall
Wrappon toilet – replaces the standard spec thetford cartridge toilet
Victron 100Ah agm battery (note-std spec does not come with a battery)
Relion LT100 LiFePO4 battery (note-std spec does not come with a battery)
STANDARD EQUIPMENT
Plumbing/Heating/Cooling
(1)-multi speed roof vent
38 gal. fresh water tank w/12v pump and sight gauge
15 gray water tank (in-frame location – not heated)
Sagiva outside & inside shower connection
S/s deep sink w/J-handle faucet and cutting board top
S/s single burner propane and removable single burner induction cooktop
Webasto (diesel or gas) airtop 2000 cabin heater
OEV hydronic system
Chassis glycol tie in for cabin in travel mode
Thetford C223CS cassette toilet
Electrical
(2)-200W roof-mounted solar panels
Victron soc display
Victron 100/30 mppt solar controller
Victron dc/dc charger
2000W victron multiplus compact 12/2000/80 inverter (w/charger) w/remote on/off
(2)-ac 110v plugs
LED PS amber exterior sidelight
LED exterior DS/Rear light
LED interior lighting
164L dc compressor fridge/freezer
Smoke/CO/LP detectors
Interior Items
Underbed storage pus a 6” queen size mattress
Snap-on vinyl window cover for entry door
Screen door
(2) dual-pane acrylic windows on the passenger and driver side in the dinette area
8 windows in the soft wall (1 on each end and 3 on each side)
51” wide (north/south) u-shaped dinette - folds down into bed
Marine fabrics for all cushions
4” medium density foam cushions
High traffic grade lonseal vinyl flooring
Powder-coated aluminum interior cabinetry
3 ply bamboo countertop and table
Starboard door and drawer fronts
Dry bath, shower pan in the entry adjacent to the toilet closet
Fire extinguisher (abc)
Standard/optional features and prices are subject to change without notice.
